Mazda MX5/Miata NB/NBFL - Washer Bottle

I wanted to tidy up my engine bay by removing the huge OEM washer bottle out of the way. Cappuccino or aluminium ones were too expensive for a washer bottle and the ones offered online were not as good as I'd want, so I set out to design my one... I ended up completely over-engineer this part with clever interior walls shape to allow printing without support structure.

This fits MX5 NB/NBFL - LHD.
MX5 NA & NB RHD under testing.

Features:
- 2 Different sizes for different printer's size (250mm Tall & 315mm tall)
- Print facing the orientation on the images. This PRINTS WITHOUT SUPPORT!
- 2L Tank (315mm bed version)
- Use the OEM pump and rubber grommet. Use some kind of lube on the grommet before inserting it (It's tight to avoid water leaking).
- Print in PETG or ASA (I printed mine in PETG and it did not leak).
- WATERTIGHTNESS WILL DEPEND ON YOUR PRINTER AND CALIBRATION. I used PETG in my Bambu H2D and it was completely watertight.
- Held in place using 2x M6 Threaded inserts (M6x8x5) and 2x M6 Bolts (M6x6). You can use the "Bolt Spacer" if your bolt is too long is M6x10 or longer.
- It leaves 10mm between the bottom of the washer bottle and cowl, so water can still flow away like OEM.
- 3D Printed threaded cap with Mazda logo imprint for easy 2 or 3 multi colour print.

Similarly to any other Washer Bottle relocation, you will need to extend wiring about 5cm.

Bambu Slicer profiles are included for your convenience.

• Use PETG (or above)
• 0.16mm Layer height for better tolerances on the threaded cap.
• At least 3 walls
• Check last image to confirm print orientation
