Caliper Storage Case Pro (Customizable TPU Inlay)

This is a professional-grade Caliper Storage Case designed to provide maximum protection for precision measuring tools. The design features a rigid outer protective shell and a soft, shock-absorbing TPU inlay to keep your caliper securely in place and protect its delicate measuring surfaces.

Key Features:

Broad Compatibility: The design is sized to fit most standard 150 mm (6 inch) calipers. (Please check your specific tool dimensions before printing).

Secure Magnet Closure: The lid and base feature four precision-fit holes for 5x3 mm magnets, providing a satisfying and reliable "snap" closure.

Fully Customizable: I have included the STEP file, allowing you to easily modify the dimensions or internal geometry to perfectly match your specific brand or model of caliper.

Professional Aesthetic: A clean, minimal design that looks great in any workshop or tool chest.

This is a multi-material print designed for durability and protection.

Machine Type: FDM (Fused Deposition Modeling)

Required Materials:

PETG or ABS: Recommended for the outer shell for high impact resistance and long-term durability.

TPU: Used for the internal inlay to provide a soft, non-marring surface for the tool.

Resolution/Layer Height: 0.2 mm is standard, but 0.16 mm will provide a cleaner finish for the magnet holes and hinges.

Infill: 20% is sufficient for the main body.

Wall Loops: Use 3-4 wall loops for structural strength around the hinge and magnet areas.

Assembly: 1. Press-fit or glue four 5x3 mm magnets into the designated corner holes.
2. Insert the printed TPU inlay into the base.
3. Connect the lid and base using the integrated hinge system.
