1/4-20 Threaded Rod 75mm Long!

So I am working on several projects that require a 1/4-20 thread configuration and prgraming this in Open-SCAD or creating in Tinkercad would be big projects. So I used a customized version of https://www.thingiverse.com/thing:193647 to produce this STL file which I can now import and use for various projects. For note, the thread OD has been standardized at 6.35mm and TPI of 1.27 and pitch of 45 to make it easier to print. Please keep in mind this WILL NOT be perfect and you will likely have to chase it with a tap (see more here: https://amzn.to/2MFCIxu) or die (see more here: https://amzn.to/2S9UptZ) if used as a bolt/rod. You can also get a complete Tap/Die set (recommended) here: https://amzn.to/2TnqcoZ

Another thing is when printing, use 1 to 1.2mm walls as you will need to cut into them with either the tap or die so give yourself plenty of material to work to with!

Major Favor: if you make one of these please post the Make and share it with the community :-) .

Also, please follow us on Thingiverse and give this a like if this came in handy and for more information on this project, please visit us at http://www.DIY3DTech.com as well as subscribe to our YouTube Channel at http://YouTube.DIY3DTech.com along with a visit to our drone site and YouTube channel at http://video-drone.DIY3DTech.com

If you are looking for one of a kind swag shop for yourself or a Maker Geek friend, visit our swag shop at http://Swag.DIY3DTech.com for unique 3D Printing, Laser Cutting and CNC swag! Too, if you want a behind the scene look at what we are working on be sure to follow us on Instagram (https://www.instagram.com/diy3dtech/)!

Using the following options:

type = rod
head_type = hex
drive_type = socket
head_diameter = 12
head_height = 5
drive_diameter = 5
slot_width = 1
slot_depth = 2
texture = exclude
thread_outer_diameter = 6.35
thread_step = 1.27
step_shape_degrees = 45
thread_length = 75
countersink = 2
non_thread_length = 0
non_thread_diameter = 0
nut_type = normal
nut_diameter = 12
nut_height = 6
nut_thread_outer_diameter = 9
nut_thread_step = 2
nut_step_shape_degrees = 45
wing_ratio = 1
inner_diameter = 8
outer_diameter = 14
thickness = 2
facets = 6
socket_facets = 6
socket_depth = 3.5
resolution = 0.5
