Interceptor wall mount with fingerprint lock

Wall bracket with fingerprint lock for the Mey Interceptor

The wall bracket can compensate for tolerances and different mounting positions of the front handle by using adapter plates and inlays in the lower support. The closing position of the handle shells can also be adjusted using inlays, even though they fit like a glove using a 3D scan.

For use, see video and photos

https://youtu.be/ARywGJTvNf0?feature=shared

The files contain a description of the print settings and step-by-step assembly instructions.

The 3mf file is for Bambu Lab printers with fuzzy skin, Hilbert surface and modifiers in the connection areas (without fuzzy skin), also in the sliding backdrop. Not all individual parts are included (inlays for rigid mount and closing position), but assembly should normally be possible.

The included printed latch (printed horizontally, solidly filled with walls) can be used for the lock, as it can withstand even strong shear forces in the holder. The printed part can also be used as a template for shortening the metal latch included with the lock.

Link fingerprint lock: length 20mm!!! see photo

https://a.aliexpress.com/_EjvVBFd

https://a.aliexpress.com/_EycgYZd

Upgrade to wall mount:

Magazine holder alone or together with the quiver holder, quiver

https://youtube.com/shorts/eA6freOCegg?feature=shared

https://youtube.com/shorts/gKtruTXoSbE?feature=shared

UPDATE Nov. 01, 2024

Holder for quiver has been optimized for printing, rear rounded contour is straightened for support on the printing plate

UPDATE Nov 02, 2024

Hilbert curve adapter plate added to surface

Static mount 2 placed on separate plate due to the very different printing times with the significantly higher components

UPDATE 15.Nov.2024

Quiver holder split for better printing result.

• first version "holder quiver" rounded edges

  • second version "holder quiver optimized" no rounded corners on the contact surface
  • third version "Holder quiver plate" + "Holder quiver clamp" optimized for better printing results

UPDATE 29.Sep.2025

Holder for magazine belt clip added. Easy to attach by replacing the wall adapter. Mounting with 5 dowel pins 5mmx25mm.

https://youtu.be/JJNPhhJWJfs?feature=shared

If the belt clip was not printed with fuzzy skin, then use the version with less play "Interceptor holder belt clip left/right smaller play".

https://ingenieurdienstleistungen-lippstadt.jimdosite.com/

See PDF in ZIP

Largest part of the wall mount 210mm X 150mm

Largest part of the upgrade (magazine holder) 210mm X 190mm
