2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)

IMG_4257.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4236.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4241.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4234.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4233.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4237.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-065817.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-065823.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-065832.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-065859.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-071013.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Fan Duct.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Inner VESA.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
JRY-SA1 Main Bracket.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Left Crossover Bracket.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Outer VESA.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Right Crossover Bracket.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Main Bracket Retainer.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Outer VESA M4.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4257.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4236.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4241.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4234.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4233.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
IMG_4237.jpg 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-065817.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-065823.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-065832.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-065859.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Screenshot-2026-03-31-071013.png 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Fan Duct.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Inner VESA.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
JRY-SA1 Main Bracket.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Left Crossover Bracket.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Outer VESA.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Right Crossover Bracket.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Main Bracket Retainer.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Outer VESA M4.stl 2017 27" iMac 5k conversion kit A1419 (should work for other years A1419)
Pubblicità
Fai un'offerta
Condividi
Aggiungi a
Make
?
Qualità della creazione: 5/5 (1 voto)
Valutazione dei membri su stampabilità, utilità, livello di dettaglio, ecc.
Licenza
Utilizzi
Formato del progetto 3D
16 file (3MF e STL) Chiudi
  • Fan Duct.3mf 135.84191899999996 × 83.850345 × 33.198623 mm
  • Fan Duct.stl 135.84191899999996 × 83.850345 × 33.198623 mm
  • Inner VESA.3mf 170.75003099999998 × 58.60000600000001 × 11.0 mm
  • Inner VESA.stl 170.75 × 58.60000600000001 × 11.0 mm
  • JRY-SA1 Main Bracket.3mf 176.900665 × 64.17100500000001 × 25.940531 mm
  • JRY-SA1 Main Bracket.stl 176.900665 × 64.17100500000001 × 25.940531 mm
  • Left Crossover Bracket.3mf 161.49807700000002 × 106.490631 × 16.5 mm
  • Left Crossover Bracket.stl 161.49807700000002 × 106.490631 × 16.5 mm
  • Main Bracket Retainer.3mf 8.0 × 14.991791999999998 × 6.972158999999998 mm
  • Main Bracket Retainer.stl 8.0 × 14.991791999999998 × 6.972158999999998 mm
  • Outer VESA M4.3mf 114.99998500000001 × 46.951729 × 115.522808 mm
  • Outer VESA M4.stl 115.0 × 46.95173 × 115.522808 mm
  • Outer VESA.3mf 115.0 × 115.000004 × 18.026958 mm
  • Outer VESA.stl 115.0 × 115.000004 × 18.026958 mm
  • Right Crossover Bracket.3mf 118.96902400000005 × 186.077954 × 21.0 mm
  • Right Crossover Bracket.stl 118.96905500000003 × 186.077954 × 21.000001 mm

Scopri di più sui formati
Ultimo aggiornamento
Data di pubblicazione
Numero del progetto 4211084
Autore del progetto PracticalPrototyping
PracticalPrototyping

PracticalPrototyping

Account certificato
Problemi con questo progetto? Segnala un problema.

Informazioni sul modello

Descrizione del modello 3D

Here is a full kit to convert A1419 to 5k monitor using JRY-W9RQUHD-SA1 from GIVIFENY store on Aliexpress. It requires cutting ram slot wider to be able to glue in a new bracket. I used 100% glue from lepage but other Gorilla glue or similar will work. I used M3x6mm socket head for retainers while the glue was drying, then removed those that interfered with the board. Inner VESA uses original bolts and M5x20 or 25mm to secure the outer VESA to the Inner. Left and right crossover brackets to case reuse original hardware, while crossovers, fan control and backlight PCB's are mounted with M2.5x6mm bolts. I attached screanshot of the fan control I used. You will need 24v to 12V converter if you want to use a fan; it is optional since the PSU is external. I also used a custom 24v to 12v converter based on AP63200WU-7 with the enable pin connected to 12 pin JST (external backlight connector) on the main board. I might provide Gerber files later for the 24-12v converter later if requested frequently. Thanks!
