PlayStation Lightbox Lamp

I designed this to be printed on any single extruder printer like Ender 3. Can easily be sliced in Cura using Z hop.

Files Included:
Back.stl
White.slt
Black.stl
LightBox PS PlayStation v3.3mf

Component Links For this Lamp 🔗
LEDs rgb 5v 🛒👉 https://s.click.aliexpress.com/e/_98Vnlw
LEDs white 5v 🛒👉 https://s.click.aliexpress.com/e/_9z6kJn
Controllers 5v🛒👉 https://s.click.aliexpress.com/e/_DkAmFej

All KS3DPrints designs are protected under copyright law. Purchasing a design does not grant you the right to sell digital files or 3D-printed models made from them without my explicit written consent.

To obtain legal permission to sell prints, join the Merchant Tier on my Patreon: https://www.patreon.com/ks3dprints

Please support the creativity and hard work of 3D artists by never sharing or reselling digital files. Your integrity keeps the community thriving!

Recommendations:
- Use PEI Sheet for textured print surface.
- Open Cura or what ever slicer you use.
- Drag and drop 3MF file to your slicer and click "Import Model". You will see all 3 parts in your slicer.
- Print first white part normally. Avoid brim.
- Print second Black part using Z hop in your slicer and set z hop height to 2mm. Enable fuzzy skin option for outer walls if you like some textured surface on the walls.
- Print the Back part individually.
- Use aluminum tape on the inside of the backplate to help light diffuse better and glue the LED's the further away from the colored design possible; placing them too close ruins the diffusion and the individual LED's become visible.

Layer 0.2
3 walls
10-15% infill
No Supports
PLA is great to print with
Perfect bed adhesion needed
