Parametric Cable & Conduit Wall Clip – Adjustable 3D Printed Mount

This parametric wall-mounted clip is designed to securely hold electrical conduits, corrugated pipes, or cable tubes against a wall using a single standard zip tie.

The pipe is locked in place by passing one zip tie through the upper rectangular slot and the lower slot, exactly as shown in the reference installation.
No metal clamps, no complex parts, no unnecessary hardware.

The design is fully parametric and created in Fusion 360, allowing you to easily adapt it to different pipe diameters.
The default configuration is optimized for 25 mm diameter pipes, but it can be adjusted for any diameter from 10 mm upward by simply changing a parameter.

Perfect for electrical installations, home automation, outdoor cabling, garages, basements, and technical rooms.

set the "diametro_tuno_clip" value from 10 to however many mm you want.

You will receive the original Fusion 360 (.f3d) file, so you can modify dimensions quickly and precisely.

Material:
PLA+ for indoor use
PETG or ABS recommended for outdoor or humid environments

Layer height: 0.2 mm

Infill: 25–35% (gyroid or cubic recommended)

Perimeters: 3–4 walls

Supports: Not required

Print orientation: Flat on the back face for maximum strength

Hardware needed:

1 standard zip tie

1 wall screw (recommended Ø6 mm, length according to wall type)
