Hexagon World Map

Hey

Here I have a Hexagon World Map for you.

The hexagons can be super print and then plug together very Easy.

The lids with the World Map must then be glued best on it.

Size of the hexagons approx 170mm x 30mm height

Tip for printing the world map.

Make by M600 or better via the Prusaslicer at Layer 6 ( if you print with 0.2) a break for the color change.

For this project I plan updates which then always come free of charge here to download.

-------------UPDATES----------------

Update 1: Online: All continents and islands have been separated. So now Leafs and Continents can be printed individually.

So you don't need the M600 function and don't have to wait for the color change.

(Pluggable.zip)

Update 2: Quarter hexagon with shell. Once without screw holes and once with screw holes for wall mounting the worldmap.

Update 3: Plug-in Leafs with cutout for the islands.

Leafs should be printed upside down.(Otherwise lots of support). This is possible without support if the printer is well set.

Update 4: Leg length of the housing Corrected.

Since the leg length from the housing has deviated slightly (84.293mm to 84.524mm) I have corrected this to the intermediate dimension of 84.409mm. Old housing remains in the files because I never had problems with it and the new file was added (Gehaus_3mm_korrigiert.stl)

Update5: Clean Update: The outer edges of the shells have been cleaned up. No more holes for the led strips and no more connectors.

Attention!!!! If you want to use the wall mount, of course you have to replace the corresponding clean shells with the originals.

To download a new zip file "Clean" there are all housings included and a PNG what should illustrate which file belongs where.

Update6 (05/21/2023): Added a normal shell blank and a blank_pluggable in case you want to expand the hexagon.

-------------Comming Soon-----------

Should you have any ideas or requests write me here via email or Instagram.

I would be very happy to receive pictures of your prints.

Also check out my other lettering and emojis.

There are always new ones coming.

Check out my Instagram profile Timeto6_3D

Kind regards

Layer Height 0.2 mm

No Supports / Pluggable Leafs should be printed upside down depending on printer with support

15% Infill
