Organizador de cables MagSafe | Cargador de sobremesa de 8 puertos

Clean Multi-Device Charging Station

Transform your messy charging setup into a clean, minimal and premium looking charging hub.
This MagSafe Cable Organizer is designed to look like a real consumer product rather than a typical 3D print.
Every cable has its own guided path, the MagSafe charger sits perfectly centered, and an internal buffer system ensures smooth cable pull-out without tangles.

Ideal for desks, nightstands or living rooms where clean aesthetics matter.

⸻

FEATURES

-Integrated MagSafe charging mount
-Six individually guided USB cables
-Internal cable-buffer system for smooth pull-out
-Front USB-A passthrough
-Magnetic bottom cassette for power cable routing
-Designed around a compact 8-port charger
-Clean footprint and professional appearance

ADDITIONAL HARDWARE

10× M3 heat-set brass inserts
10× M3 × 6 mm cylinder-head screws
10× neodymium magnets Ø10 × 2 mm
4× silicone anti-slip feet (8 × 2 mm)

ELECTRONICS

USB Desktop Charger

Fits chargers up to:
101 × 92 × 33 mm (L × W × H)

MagSafe Charger

Diameter: 56 mm
Height: 5.5 mm
Connector: USB-C

Cables

-C7 right-angle power cable, 50 cm
-6× USB charging cables, 50 cm
-USB-A male → USB-A female extension (front port)

TOOLS REQUIRED

-Soldering iron (for heat-set inserts)
-2.5 mm Allen key
-Cyanoacrylate (super glue)
-Optional: double-sided tape

ASSEMBLY MANUAL

A complete illustrated step-by-step PDF manual is included with this model.
It also contains direct purchase links for all required hardware and electronics,
including the exact parts used during development to ensure perfect compatibility.

Even if you are new to multi-part 3D prints, the manual makes the process straightforward.

DISCLOSURE

All engineering and design work is original.
The manual’s illustrations were generated with AI because, after spending far too long experimenting with them, starting from scratch manually wasn’t reasonable anymore.

This model was designed specifically for FDM printing, with tolerances optimized for reliable fit on typical consumer printers.
PLA or PETG is recommended, with around 15% infill and standard wall settings.

Most parts print without supports.
Only the shell requires support for the lower internal holders (these surfaces are hidden after assembly).

Magnets are inserted during printing — simply pause at the marked layers and place Ø10×2 mm magnets.

General layer heights:
0.2–0.3 mm depending on component

Full printing guidance and detailed part-by-part settings are included in the PDF manual.
