AGM-114 地狱火导弹 - 全尺寸 - 可飞行

This is a design I did for one of my favorite missiles. The AGM-114 Hellfire. I have deigned this Missile/Rocket to be flyable using Cesaroni Pro-X 54 Reloadable High-Power Rocket Motors.

The rocket is designed to Full Scale, meaning that it has a diameter of 158 mm (6.2 in) and a length of 163 cm (61 in). I have designed it to be printable in sections. The design has internal structural reinforcements as well as execution gases channels, to safely deploy a parachute at altitude.

This build will require the following:

1x Cesaroni Pro-X54 reload casing
1x Cesaroni Pro-x54 rocket motor
1x 100" parachute for safe recovery
1x Rocket deployment electronics (user selectable)
Shock Cord
Custom Launch Rail

This design is intended to be manufactured using several printing technologies:

FDM print the rocket body on a CR-10 MAX, using 4 perimeters, 4 top and 4 bottom layers, and 66% infill.

Print the nose cone using SLA clear resin. There is space to install a camera in the nose.

Print the fins and mounts using SLS-Nylon 12.
