π64 (mini N64 case for RPi3 & 4)

Качество творения: 5,0/5 (1 проголосовать)
Оценка участников по печатаемости, полезности, уровню детализации, т.д.



Описание 3D-модели

UPDATE: 11/22/2019
This now includes a version of the case that is compatible with the Raspberry Pi 4. The only differences are in the top and bottom of the case, all other parts have stayed the same.

UPDATE: 1/14/2019
Inspired by Barrymanman's remix of the bottom of the case, I decided to make an alternate case bottom that is broken into 5 pieces to making printing easier. The new part deviates a bit more from the original N64 shape but since it's on the bottom maybe it's not a big deal. If you choose to use the alternate case bottom you'll have to print 2 of the front and aft feet each then glue them onto the bottom. I hope this helps.

UPDATE: 5/29/2018

If you are looking to print this in the exact colors of the original N64 console have a look at what ColorFabb is offering. Custom colored filament! https://all3dp.com/colorfab-launch-new-color-demand-filament-service-june/?omhide=true&utm_source=Newsletter&utm_campaign=74bff4c524-Newsletter&utm_medium=email&utm_term=0_9dffeeddae-74bff4c524-397363897

UPDATE: 5/16/2017
Stemming from KyleARectors idea to use the game cartridge to house a cooling fan, I have added a new game cartridge to the build files that is designed for a 30mm x 30mm x ≤10mm fan to mount onto the bottom. I designed it to fit the Raspberry Pi fan sold by Adafruit (https://www.adafruit.com/product/3368) but any fan of the same size will fit. The mounting holes are sized for M2.5 screws.

Inspired by all of the brilliant RetroPie cases out there, I decided to create a new one based on my favorite video game console from my childhood. I give you the π64!

First off I must give credit where it is due.
• Bruno Amaral created an excellent model from which I started. You can find it here: https://grabcad.com/library/nintendo-64-console-1
• Thanks to my friend Andrew Holt for printing the parts for me on his FlashForge Dreamer.
• Thanks to my friend Jared Larsen for doing the soldering.

I wanted this to look and function as close to the original as possible. The case is built to house a Raspberry Pi 3 model B. Since the original N64 console has a door on top to access the expansion memory I made this the access for the microSD slot with the use of an extension cable. It has a functioning reset button and the power switch has a slot to accommodate a switch although I decided not to put one in my case. To use a reset switch a small amount of soldering does need to be performed on the PI. The original N64 console has a red power LED on the front. Rather than wiring in an LED I experimented with a fiber optic line that pipes the light from the power or processor or both LEDs to the front of the console. The light pipe idea works surprisingly well. I am quite satisfied with the results over all.
If you’re not into games you can always use your Raspberry Pi as a Kodi media player or anything else you like.

Required parts:

• 3D printed parts shown above (If you want to print the case in the proper colors I recommend the following filaments or you can print them in white and paint them like I did. All model units are in millimeters.)

For the console: Dark Grey filament from 3DPrima, http://www.3dprima.com/en/filaments-for-3d-printers/pla-175mm/primaselect-pla-175mm-750-g-dark-grey.html.

For the game cartridge and controller ports: Earl Grey filament from Faberdashery, http://www.faberdashery.co.uk/products-page/print-materials/earl-grey/

• Raspberry Pi 3 model B with power cord and video cable

• 8GB microSD card with software installed, https://www.raspberrypi.org/downloads/noobs/, https://retropie.org.uk/download/

• 7, M2.5 screws 6mm long (#3 1/4in long screws will also work)

• Super glue

Optional parts:

For relocating microSD port:
• MicroSD extension cable, http://www.ebay.com/itm/TF-To-Micro-SD-TF-Flex-Zip-Extension-Cable-Adapter-for-GPS-DVD-Mobile-Phone-TW/131878023354?_trksid=p2045573.c100505.m3226&_trkparms=aid%3D555014%26algo%3DPL.DEFAULT%26ao%3D1%26asc%3D41451%26meid%3Da58424d4c10747dc8454a0a44f50975f%26pid%3D100505%26rk%3D1%26rkt%3D1%26 (remove the casing from the port end)

For installing a reset switch:
• A standard PC reset switch, http://www.ebay.com/itm/ATX-PC-Computer-Motherboard-Power-Cable-Switch-On-Off-Reset-Computer-Replacement-/360774703348?hash=item53ffd918f4:g:TWkAAOSwnDZT~faO
• A 2 pin male header soldered into the holes labeled “run” on the Pi board, http://www.mouser.com/ProductDetail/Harwin/M20-9990246/?qs=Jph8NoUxIfWjw4WmyRvzag%3D%3D&gclid=CPLXg-zOhtICFRKRfgodGTsFUg (you can swipe one from any old computer motherboard)

For piping the LEDs to the front of the case:
• A short length of 1.8mm clear plastic cord, http://www.michaels.com/stretch-magic-bead-jewelry-cord-1.8mm-x-3m/10315671.html#q=bead+cord&pmpt=qualifying&sz=24&start=25

For installing a power switch:
• I’m afraid you’re on your own, but I did leave a cutout for a switch.

For the console and game labels:
• Print the included PDF at 100% scale. Labels look best when printed on photo paper.
• Thanks to "bobotrax" for creating the alternate game label.

Enjoy building your own!

Check out my other 3D print projects here:

Информация файла 3D-принтера

  • Номер проекта: 135907
  • Формат 3D-дизайна: PDF и STL Детали папки Закрыть
    • alternate_game_label_by_bobotrax.pdf
    • foot_aft.stl
    • foot_front.stl
    • game_cartrige%2Bfan.stl
    • game_cartrige.stl
    • game_label%2Bpi64.pdf
    • mem_exp_clip.stl
    • mem_exp_lid.stl
    • mem_exp_lid_2.stl
    • pi3_case_bottom.stl
    • pi3_case_bottom_alt.stl
    • pi3_case_top.stl
    • pi4_case_bottom.stl
    • pi4_case_bottom_alt.stl
    • pi4_case_top.stl
    • pi64_logo_3D.stl
    • ports.stl
    • power_switch.stl
    • reset_button.stl
