U-Hook personnalisable

Description du modèle 3D

Parametric hook, universal and very strong.

I’ve been looking a while for a parametric hook modeling, but I didn’t found any available model that ideally combines strength and customizing possibilities. So I tried to create the model I wanted. This is an attempt for a universal and very strong parametric hook, easily 3D printable as a "finished product".

I did a "stress test" with my parametric U-Hook in its default configuration. The hook had been printed in PLA, with 2 perimeters, 0.2 mm layer height, and 20% infill.
It supported a weight of 47,4 Kg.

SCAD file, full PDF documentation (in English and French), and 4 STL samples are inside the downloadable zip package.
More information on my website :
http://www.sergepayen.fr/en/parametric-u-hook

To customize this object, you need OpenScad software (free and open-source). It's very easy if you just want to customize an existing SCAD file. I wrote a little tutorial about "how to use a parametric file", that explain how to use OpenScad to customize a parametric object :
http://www.sergepayen.fr/en/how-to-use-a-parametric-file

Paramètres d'impression 3D

Rafts: Ne concerne pas
Supports: Non
Hauteur de la couche: 0.2
Remplissage: 20%

  • Format du fichier 3D : ZIP

Mots-clefs

Créateur

Abonnés Abonnements 0
Téléchargements 697

www.sergepayen.fr

Convinced by 3D printing potential as a vector of social and economic changes, I take part in this movement by designing "file-objects". I believe 3D printing will become a major alternative production method, decentralized and accessible, that may profoundly change relationship between "users" and "products".

License

CC BY NC SA
