Vanquish VS410 Portal Interior, shift servos and battery relocation
:still():format(webp)/https://files.cults3d.com/uploaders/14691721/illustration-file/c6d41c0b-322d-41cb-bf19-a68ef8509014/20220614_205908.jpg)
/https://preview3d-images.cults3d.com/jr7edo6utsz6041knrmevkjch00f)
/https://preview3d-images.cults3d.com/qy1nrspai879gxati8fgndubhdha)
/https://preview3d-images.cults3d.com/0db1gj50w21juob5x1dp6zcr8a39)
/https://preview3d-images.cults3d.com/b5g56c03mep92bfpku0wit053cqt)
/https://preview3d-images.cults3d.com/4xa0lzyo9sos9eiddvsv5reyxd60)
/https://preview3d-images.cults3d.com/1i8cuarv9voovu92tt7fiye0j7wc)
/https://preview3d-images.cults3d.com/e818giie1mxs5x7xgips67fy65t5)
/https://preview3d-images.cults3d.com/8dsvytl3dlr6ufkjbiz1i6y79wu2)
/https://preview3d-images.cults3d.com/ydu2yvpyh7yjs300wcdaf65z64og)
/https://preview3d-images.cults3d.com/dj2sf8dup3kae2ko31h71csnipjx)
/https://preview3d-images.cults3d.com/9fzbueqy0b82g1oywl931izm7qj0)
/https://preview3d-images.cults3d.com/met2ky5x0385xjp0hto1kuhqj9vx)
/https://preview3d-images.cults3d.com/v7q409by9z1ac8hfjgj8pdhr5rt2)
/https://preview3d-images.cults3d.com/14qjhxjlmz16dkf7gx8ei6fl9soc)
/https://preview3d-images.cults3d.com/fy7pyy13lhju7ld7h9ve43yh0ihf)
/https://preview3d-images.cults3d.com/484ac86wx0l52qtzt84xk4m29auc)
/https://preview3d-images.cults3d.com/vrty33gvgqmp0q7bdscwxxnma6e6)
/https://preview3d-images.cults3d.com/qshuoz44rhjv5jswha7dqfm3p2ff)
/https://preview3d-images.cults3d.com/vnluz5z92qsxwd9erohix4ygl8st)
/https://preview3d-images.cults3d.com/fv8qtbl0xat8xqv0hmnsazye3fyh)
/https://preview3d-images.cults3d.com/8sybauyxt67146nt9tx90r0hpzqz)
?
Creation quality:
0.0/5
(0 votevotes)
Evaluation of members on the printability, utility, level of detail, etc.
Your rating:
0/5
- 2.1k views
- 3 likes
- 1 download
- 0 comments
- 0 makes
Designer
3D model description
I wanted to have a full interior in My truck so redesigned the shift servo mounts and Battery postions to clear up as much space as possible. The servo relocation and battery trays can be used without the interior but the interior cannot be used without first installing the servo and battery tray.
It is set up to use a 3S 2200mah LiPo but can take longer ones if you can find them. https://amzn.to/3biXh2Z
2 JX mini Waterproof servos with Boomracing Servo Horns. The shift Linkages will need to be custom made.
http://asiate.es/aff?l=162286&i=35116
http://asiate.es/aff?l=155366&i=35116
This is a big set of files and includes the following
Interior Base
Seats(driver seat has a slot to attach a figure as seen in pics)
Dash(full or in parts)
door panels and door accessories
Servo relocation trays and retainers
Battery and ESC relocation tray(Most ESC's should fit)
Wire cover (use if utilizing rear box for electronics)
after printing, cleanup and paint, mount the finished door panels like you would the lexan interior via the door handle and retaining bracket that is included with your kit. Assemble the interior with or without figurines. Wiggle it in by flexing the body till the Door panels fits snug with the interior base. at the rear of the base there is a space for 2 stock screws that screw into the rear bed cage like it would with just the body. if your body is already assembled you may have to remove those screws prior to installing the interior.
As for printing. Take a look at the files and determine if you want the full parts or separate parts to be assembled allowing for different printing orientations and finishes. For instance I printed the plain door panels face down on a textured surface to give them the look you see in the pictures.
3D printing settings
I printed in PETG
Some parts will need supports, others none but I will leave these details in your capable hands.
3D printer file information
- Design number: 763952
-
3D design format: STL Folder details Close
- 2JZ.stl
- 2JZ_2.stl
- Base interior.stl
- Battery tray.stl
- Cluster.stl
- Dash 1.stl
- Dash 2.stl
- Dash 3.stl
- Dash Stuff.stl
- Drivers Seat.stl
- Full Dash.stl
- Full Left Door Panel.stl
- Full Right Door Panel.stl
- GloveBox.stl
- Micro Servo clamp.stl
- Passenger Seat.stl
- Plain Door Panels.stl
- Separate Door Panel parts.stl
- Servo plates.stl
- Snorkel.stl
- Snorkel.stl
- Publication date: 2022-06-24 at 03:19
