Vanquish VS410 Phoenix Mini Servo Mounts/Relocation
:still():format(webp)/https://files.cults3d.com/uploaders/14691721/illustration-file/fbf41bfe-d0fe-467e-94a4-41e76fd13def/20220623_223750.jpg)
/https://preview3d-images.cults3d.com/vnluz5z92qsxwd9erohix4ygl8st)
/https://preview3d-images.cults3d.com/fv8qtbl0xat8xqv0hmnsazye3fyh)
/https://preview3d-images.cults3d.com/8sybauyxt67146nt9tx90r0hpzqz)
?
Creation quality:
5.0/5
(1 votevotes)
Evaluation of members on the printability, utility, level of detail, etc.
Your rating:
0/5
- 3.2k views
- 2 likes
- 7 downloads
- 0 comments
- 0 makes
Designer
3D model description
Bring your center of gravity and weight down by installing smaller Dig and overdrive servos and lowering their mounting points. Not to mention making room for a full interior. This set is designed to use the new Mini JX Waterproof servos along with BoomRacing's servo saver set. Both high quality and very affordable.
Servos:
http://asiate.es/aff?l=162286&i=35116
Servo Savers:
http://asiate.es/aff?l=155366&i=35116
The servos are fastened using the mounting bracket and secured using some Self Tapping 2mm screws.
In the pictures I am using the custom Battery tray designed for smaller 3S 2200mah LiPo packs but the stock tray may be used with slight mods.
You will need to make some short links to connect the servo's to the transmission arms. Approximatly 32mm Hole to Hole and the Servo Horn screw size is M2
3D printing settings
Printed In PETG or PLA without supports.
