Toy train locomotive construction set

?
Creation's quality: 3.9/5 (4 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 7.2k views
  • 47 likes
  • 66 downloads

3D model description

Toy locomotive construction set. Use included screws to build the locomotive. Contains 12 pieces.

Recommended screwdriver: https://www.thingiverse.com/thing:4070791

See the train in the action: https://www.youtube.com/watch?v=dHmcyKtLaoY

UPDATE #1: added screw with hole through

UPDATE #2: fixed integrated support in rear_bumper.stl. Added version without supports so you can use your own.

UPDATE #3: missing rivets in watertank.stl

3D printing settings

Print settings:
0,2 mm
Gyroid infill 10 %
2 perimeters


All parts are oriented as they should be oriented on the print bed
No supports needed
It's recommended to use skirt for chimney.stl for better bed adhesion


Special print instructions:
watertank_front.stl - these should be printed in two colors, use change filament color at layer height
headlight_L.stl, headlight_R.stl - these should be printed in two colors too

Parts finishing:
- remove custom supports from rear_bumper.stl
- use sharp knight to remove custom bridges inside holes in parts watertank.stl and chimney.stl
- you can colorize rivets on watertank, acrylic colors works great

Assembly:
- recommended is to use superglue (cyanoacrylate)
- glue four chassis parts together (chassis_bottom.stl, chassis_bottom_part.stl, chassis_middle.stl and chassis_top.stl), to help with alignment, use provided pins pin_long_2x.stl
- glue two roof parts together (roof_bottom.stl and roof_top.stl), to help with alignment, use provided pins pin_short_4x.stl
- glue headlights to the plow (headlight_left.stl, headlight_right.stl and plow.stl), to help with alignment, use provided pins pin_short_4x.stl
- glue chimney_ring.stl to the chimney.stl
- glue window frames to the cab
- glue inside wheels to the wheels (wheel_inside_4x.stl and wheel_4x.stl)

  • 3D file format: PDF and STL
