Scorpion EVO Strike Style MLOK Handguard

Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.


Licence CULTS - Private Use
Last update 2022-07-10 at 19:35
Publication date 2021-12-05 at 18:48
Design number 577916
3D design format
STL Folder details Close
  • Dummy supressor - Long (140mm).STL
  • Dummy supressor.STL
  • Handguard S style.STL
  • Lock Ring.STL

Learn more about the formats

3D printer file info

3D model description


Eng :

Today's file is a Mlok handguard for the ASG scorpion evo I did for a friend. It's inspired from the Strike one.

There's 3 parts to print, the handguard, the lock ring, and the dummy supressor.

To assemble it, insert the lock ring in the handguard, screw on each face with some FHC M3*10 screws.

Then, put the handguard on the gun, install the big nut like on the stock handguard, and finally put the dummy supressor to hide the nut, and complete the build. Secure it with 2 FHC M3*10 screws on each side.

Hardware needed : 11 M3*10 FHC screws

Note: You'll be able to use a tracer, just replace the silencer with it.

EDITED 10/07/22 : I've met a player that purchased the design & wanted a longer supressor so I did one which is 5cm longer


Today's file is a MLOK handguard for scorpion evo asg inspired by Strike. There are a total of 3 parts to print: the handguard itself, the clamp ring holder, and the fake silencer.

To assemble it, insert the bracket from the front of the handguard and screw it on each side with M3*10 FHC screws. Then, place the handguard on the replica as if it was the original one, tighten it with the original clamping ring, then come and slide the fake silencer by the front of the handguard. Fix it using two FHC M3*10 screws on each side of the handguard.

Hardware required: 11 FHC M3*10 screws

Note: You can remove the silencer and use a tracer instead, it will fit lightly in the handguard.

EDIT 10/07/22: I met a player who wanted a longer silencer, so I added a 5cm longer silencer.

3D printing settings

Walls/Bottom/Top layer : 2mm

Infill : 30% or Higher

Material : I used PLA


Page translated by automatic translation. See the original version.
