PIAGGIO VESPA - ENGINE

Advertising
Share
Add to
Make
?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
Licence CULTS - Private Use
Publication date 2023-06-20 at 22:13
Design number 1282581
3D design format
STL Folder details Close
  • Air Filter.stl
  • Carburetor (manifold).stl
  • Carburetor.stl
  • Carter (esterno).stl
  • Carter (interno).stl
  • Cylinder (head).stl
  • Cylinder.stl
  • Engine stand.stl
  • Fan (cover).stl
  • Fan.stl
  • Ganasce freno.stl
  • Mozzo ruota.stl
  • Pedivella accensione.stl
  • Pin (3.5x10mm).stl
  • Tire (sculpted).stl
  • Tire (slick).stl
  • clutch cover.stl
  • exhaust (manifold).stl
  • exhaust (muffler).stl
  • wheel complete (monoblock).stl
  • wheel rim 1.stl
  • wheel rim 2.stl

Learn more about the formats
motabas

motabas

3D printer file info

3D model description

The legendary two-stroke engine of the scooter Piaggio Vespa, Dell'Orto SHB carburettor and air filter, muffler and wheel complete with tire (2 types of tyres), the wheel hub can be disassembled, the engine cooling fan rotates.
The kit includes a display stand to support the engine, the whole is made with a high level of detail in different parts to be assembled together.

Disclaimer:
- The resale of my files is NOT allowed
- Printing for commercial use is NOT allowed
For authorizations and concessions please contact me here on Cults.

3D printing settings

The photos represent the engine made with a resin printer, some photos are renderings of the project I made.
It is possible to print with FDM printer at moderate speed but obviously the level of detail will be lower and in some cases the supports will be necessary.
These are my printing parameters using Elegoo printers and YAJO standard resin.

PRINTER............BASE EXPO....NORMAL EXPO....RES

JUPITER............37sec.............2,0sec.................0,050mm

MARS 2 PRO.......45sec.............4,5sec.................0,050mm

SATURN.............35sec.............3,5sec.................0,050mm

Change scale:

1/10 > 1/25 -40,00 %

1/10 > 1/24 -41,66 %

1/10 > 1/18 -55,55 %

1/10 > 1/12 -83,33 %

1/10 > 1/8 -125 %
