Overdrive Micro servo mount Vanquish vs410 Phoenix

IMG_5402.jpg Overdrive Micro servo mount Vanquish vs410 Phoenix
OD-Micro-Mount-Slicer-view.jpg Overdrive Micro servo mount Vanquish vs410 Phoenix
IMG_5403.jpg Overdrive Micro servo mount Vanquish vs410 Phoenix
IMG_5404.jpg Overdrive Micro servo mount Vanquish vs410 Phoenix
IMG_5409.jpg Overdrive Micro servo mount Vanquish vs410 Phoenix
PDI-HV1151MG-Servo-dimensions.jpg Overdrive Micro servo mount Vanquish vs410 Phoenix
VS4-10 PHOENIX OD MICRO SERVO MOUNT.stl Overdrive Micro servo mount Vanquish vs410 Phoenix
Advertising
Share
Add to
Make
?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 3.4k views
  • 1 like
  • 26 downloads
Licence CULTS - Private Use
Publication date 2023-02-12 at 19:57
Design number 1060613
3D design format
STL Folder details Close
  • VS4-10 PHOENIX OD MICRO SERVO MOUNT.stl

Learn more about the formats
3D model size X 40.2 × Y 56.3 × Z 15.4 mm
007jones007

007jones007

3D printer file info

3D model description

First thing to note is that I would recommend using the servo I did for fitment reasons, or at least try to confirm that it will fit from the measurements I gave of the current servo I have. I don't believe the Micro99 servo will fit as it is too long.

Servo I used: JX PDI-HV1151MG 4.5kg Digital Metal Gear HV Micro Servo https://a.co/d/3al2qkU

I used the servo screws that come in the phoenix kit.

I used the original phoenix OD linkage that comes in the kit.

I used the servo horn that comes with the servo. I mounted the stock link at 13mm from the center of the horn mount hole. Drilled the horn hole to 2.9mm and taped to m3 size. Can add a nyloc nut if desired.

Video Link: https://youtu.be/hol8i73Gf88

3D printing settings

Inland PLA+ is what i used for these mounts.
