MODULAR WALL MOUNT DISPLAY FOR 1/64 DIECAST (HOT WHEELS, MATCHBOX, ETC)

NOTE: PA1© - FOR FULL ACCESS TO ALL MY MODELS, + EXCLUSIVE STLs AND A COMMERCIAL LICENSE FOR SELLING YOUR PRINTS, YOU CAN JOIN MY PATREON HERE:

https://www.patreon.com/PA1_MAKER

Nice and easy wall mount display for your 1/64 diecasts, modular with many type of background details. Can be awsome in your child's bedroom too!!!

Fits Hot Wheels, Matchbox, GreenLight or any other 1/64 diecast.

-100% support free.
-Everything is already placed in the right orientation for optimum
printing.
-Hundred of possibilities
-More kit to come
-Fast to print
-Hidden screws, everything holds with a simple dovetail bracket
screwed to the wall.

you have 3 types of dovetails:
100mm = For one display
200mm = For two displays side by side
300mm = for Three displays side by side

There's also a file called "magnetic base". It was asked by one of my followers, and you can mount the display on a steel file, metallic shelve or any other metallic surfaces.You don't need the dovetails for this one. But you will need 13mm x 3mm magnets.

Also included:

-Street lights (left, right and center)
-Jersey barrier
-Cones
-Fence
-Brick wall

So you can make "construction zones", "Racing scenery", "Street scenery" etc etc... Undreds of possibilities, depending on which cars you wanna display!!!

-5 signage (identification plates) are included:
-classic
-racing
-special
-Th (Treasure hunt)
-Sth (Super threasure hunt)

Assembly: Simply glue the fences to the base, install the dovetail on the wall with No.4 screws, and slide the base into place on the dovetail.

Note: For the 100mm dovetail, you don't need 3 screws. Only 2 are enough. The middle one is only there in case your wall or the dovetail is not straight.

The signage can be hold in place with tack-n-stick (the blue gum that's sticks to anything). So you'll be able to change it anytime.

You can use double face tape between each module to keep them aligned.

Now you have to put your nicest car on it! :p

Got questions? Send me a message! :)

Have fun!!!

0.3mm layer height for the base. Quick and easy print.
0.2mm layer height or smaller for detailed parts.
4 or 5 walls for the street lights
3 walls for all the other parts
