Kyosho Ferrari F40 wheels and tires

Did you 3D print this model?

3D model description

Accurate model of the 1992 Kyosho F40 wheels.

F40-tire01.stl is a reproduction of Kyosho W-5054 tires.

F40-wheel-20inch.stl are accurate reproductions of the old 2,0" standard wheels and fit Kyosho tires like the following:
W-5053
W-5054
W-5055
W-5056 (I think)
W-5058
W-5059 (I think)

F40-wheel-22inch.stl are 2,2" versions of the same wheel. They have less offset too so they sit within the body and don't stick out. These fit modern 57x80 rally tires like HPI 108076 and similar. They also fit 4WD front buggy tires.

The support pillars under the wheels snaps off easily with the help of needle nose pliers if the wheels are printed with good cooling.

3D printing settings

Tires:
One perimeter, 0,16 mm layer height, 4 bottom layers and 12 top layers with 8% infill is what I used.

Wheels:
Two perimeters and 0,2 mm layers for the first 27 mm, and then 0,08 mm layer height for the rest for better detail on the visible part. 5-10% infill is fine. Use high strength cooling.
