3D model description
Piece I use in education.
In the STL files, you will find :
2 (different) spur gears (one with the assembly).
One helical gear .
the helical shaft-pinion assembly also shows the shoulder assembly,
Key
2 elastic rings (circlips).
+(Maj) Spline assembly
- spur gear (pinion Z=10, wheel = 40, module 2)
This saves me from walking around with steel technology items in my binder while allowing for more visually understandable parts.
Gears, however, can be used for a variety of purposes.
video on making spur gears with solidworks https://www.youtube.com/watch?v=V8vpD5wp7YU
3D printing settings
RAS
3D printer file information
- Design number: 22705
-
3D design format: STL Folder details Close
- Cannelure femelle.STL
- Cannelure male.STL
- Clavette.STL
- Pignon m2 Z10.STL
- anneau elastique.STL
- arbre dentree.STL
- arbre-inter-5.STL
- arbre-sortie-7.STL
- circlips.STL
- clavette-a-sortie.STL
- pignon droit type2.STL
- pignon-sortie-6.STL
- pignonHELICO.STL
- roue dent m2 Z40.STL
- roue dentee droit type2.STL
- roueHELICO.STL
- Last update: 2023-01-12 at 13:34
- Publication date: 2018-03-18 at 13:29
