Camper Cap for the RC4WD Blazer Body

20211003_175356.jpg STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
20211003_175421.jpg STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
20211003_175426.jpg STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
20211003_175433.jpg STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
20211003_175439.jpg STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
20211003_175442.jpg STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Screen-Shot-2021-10-03-at-11.32.05-PM.png STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Screen-Shot-2021-10-03-at-11.32.24-PM.png STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Screen-Shot-2021-10-03-at-11.32.40-PM.png STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Screen-Shot-2021-10-03-at-11.34.05-PM.png STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Screen-Shot-2021-10-03-at-11.34.45-PM.png STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Bumper.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Cabinet.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Counter.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
door.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Drain.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Left Bench.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
mid-rear_assembly_Brackets.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
mid.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Nose window Template.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Nose.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Plug.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Rear Window Template.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Rear.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Right Bench.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Side Window Tempaltes.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Step mount.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Steps.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Vent 1.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Vent 2.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Vent 3.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Window frame left.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Window Frame Nose.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Window Frame Rear.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Window frame right.stl STL file Camper Cap for the RC4WD Blazer Body・3D printing design to download
Share
Add to
Make
?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

Designer

TLW3D

TLW3D

3D model description

Here is the assembly Video
https://youtu.be/rSxxrq9t0bw

Working door and stow-able steps.
full interior that you can choose not to use if you want a work type environment.

Window frames with templates to cut your windows from Lexan or other clear material.

Slots for 6 10mm LED lights
Magnetic door latch

Hardware
10pcs M3x10mm Socker cap
2pcs M3x22mm Socket Cap
10pcs M3x10mm Flathead
8pcs M3x6mm Flathead
10pcs M3 Hex Nut
8pcs M3 8x8mmm square nut(actually +/- 7.5x7.7mm)

Some parts not shown in the pictures are the vents and drain.
They can be printed and glued where-ever you see fit

Quick assembly instructions: DO NOT OVERTIGHTEN
once all the supports cleaned use the M3 hex nuts, M3x10mm screws along with the Mid rear assembly brackets with M3x6 screws and M3 Square nuts to assemble the main shell.

Insert the Hex nuts into the 4 points on the lower inside section of the shell before installing any of the interior parts. also a good idea to do any finishing on the internal items before installation.

Windows and frames could be done after everything else is complete and installed on the body.

3D printing settings

I printed it in PETG
Orientation is whatever works for you

3D printer file information

  • Design number: 534831
  • 3D design format: STL Folder details Close
    • Bumper.stl
    • Cabinet.stl
    • Counter.stl
    • Drain.stl
    • Left Bench.stl
    • Nose window Template.stl
    • Nose.stl
    • Plug.stl
    • Rear Window Template.stl
    • Rear.stl
    • Right Bench.stl
    • Side Window Tempaltes.stl
    • Step mount.stl
    • Steps.stl
    • Vent 1.stl
    • Vent 2.stl
    • Vent 3.stl
    • Window Frame Nose.stl
    • Window Frame Rear.stl
    • Window frame left.stl
    • Window frame right.stl
    • door.stl
    • mid-rear_assembly_Brackets.stl
    • mid.stl
