3D model description




3D printing settings



Layer Height: 0.1 mm

Initial Layer Height: 0.3 mm

Line Width: 0.4 mm

Wall Line Width: 0.4 mm

Outer Wall Line Width: 0.4 mm

Inner Wall(s) Line Width: 0.4 mm

Top/Bottom Line Width: 0.4 mm

Infill Line Width: 0.4 mm

Skirt/Brim Line Width: 0.4 mm

Support Line Width: 0.4 mm

Support Interface Line Width: 0.4 mm

Support Roof Line Width: 0.4 mm

Support Floor Line Width: 0.4

Initial Layer Line Width: 100%.


Wall Thickness: 0.8 mm

Wall Line Count: 2

Outer Wall Wipe Distance: 0.2 mm

Top Surface Skin Layers: 0

Top/Bottom Thickness: 0.8 mm

Top Thickness: 0.8 mm

Top Layers: 8

Bottom Thickness: 0.8 mm

Bottom Layers: 8

Top/Bottom Pattern: Lines

Bottom Pattern Initial Layer: Lines

Top/Bottom Line Directions: [ ]

Outer Wall Inset: 0 mm

Compensate Wall Overlaps: Check

Compensate Outer Wall Overlaps: Check

Compensate Inner Wall Overlaps: Check

Fill Gaps Between Walls: Everywhere

Horizontal Expansion: 0 mm

Initial Layer Horizontal Expansion: 0 mm

Z Seam Alignment: Sharpest Corner

Ignore Small Z Gaps: Check

Extra Skin Wall Count: 1


Infill Density: 20% (all parts of the connectors should be printed at

100% infill)

Infill Line Distance: 4.0 mm

Infill Pattern: Grid

Infill Line Directions: [ ]

Infill Overlap Percentage: 10

Infill Overlap: 0.04 mm

Skin Overlap Percentage: 5

Skin Overlap: 0.02 mm

Infill Wipe Distance: 0.1 mm

Infill Layer Thickness: 0.1 mm

Gradual Infill Steps: 0

Infill Before Walls: Check

Minimum Infill Area: 0 mm2

Skin Expand Distance: 0.8

Top Skin Expand Distance: 0.8

Bottom Skin Expand Distance: 0.8

Maximum Skin Angle for Expansion: 90

Minimum Skin Width for Expansion: 0.0


Enable Retraction: Check

Retraction Extra Prime Amount: 0 mm3

Retraction Minimum Travel: 0.8 mm

Maximum Retraction Count: 90

Minimum Extrusion Distance Window: 6.5 mm

Nozzle Switch Retraction Distance: 16 mm

Nozzle Switch Retraction Speed: 20 mm/s

Nozzle Switch Retract Speed: 20 mm/s

Nozzle Switch Prime Speed: 20 mm/s


Print Speed: 45 mm/s

Infill Speed: 50 mm/s

Wall Speed: 22.5 mm/s

Outer Wall Speed: 22.5 mm/s

Inner Wall Speed: 45 mm/s

Top/Bottom Speed: 15 mm/s

Support Speed: 45 mm/s

Support Infill Speed: 45 mm/s

Support Interface Speed: 30 mm/s

Support Roof Speed: 30mm/s

Support Floor Speed: 30 mm/s

Travel Speed: 80 mm/s

Initial Layer Speed: 15 mm/s

Initial Layer Print Speed: 15 mm/s

Initial Layer Travel Speed: 26.6667 mm/s

Skirt/Brim Speed: 15 mm/s

Maximum Z Speed: 0 mm/s

Number of Slower Layers: 2


Combing Mode: All

Avoid Printed Parts when Traveling: Check

Travel Avoid Distance: 0.625 mm


Enable Print Cooling: Check

Fan Speed: 100%.

Regular Fan Speed: 100% Check

Maximum Fan Speed: 100%

Regular/Maximum Fan Speed Threshold: 10 s

Initial Fan Speed: 0%

Regular Fan Speed at Height: 0.3 mm

Regular Fan Speed at Layer: 2

Minimum Layer Time: 5 s

Minimum Speed: 10 mm/s


Enable Support: Check

Support Placement: Everywhere

Support Overhang Angle: 60

Support Pattern: Zig Zag

Connect Support ZigZags: Check

Support Density: 15

Support Line Distance: 1.3333 mm

Support Z Distance: 0.3 mm

Support Top Distance: 0.3 mm

Support Bottom Distance: 0.3 mm

Support X/Y Distance: 0.7 mm

Support Distance Priority: Z overrides X/Y

Minimum Support X/Y Distance: 0.2 mm

Support Stair Step Height: 0.3 mm

Support Stair Step Maximum Width: 5.0 mm

Support Join Distance: 2.0 mm

Support Horizontal Expansion: 0.2 mm

Support Infill Layer Thickness: 0.1 mm

Use Towers: Check

Tower Diameter: 3.0 mm

Minimum Diameter: 3.0 mm

Tower Roof Angle: 65

Build Plate Adhesion

Build Plate Adhesion Type: Brim

Skirt/Brim Minimum Length: 250 mm

Brim Width: 8.0 mm

Brim Line Count: 18

Brim Only on Outside: Check

Mesh Fixes

Union Overlapping Volumes: Check

Merged Meshes Overlap: 0.15 mm

Special Modes

Print Sequence: All at Once

Surface Mode: Normal

3D printer file information

  • Design number: 286958
  • 3D design format: STL Folder details Close
    • 1.stl

    Learn more about the formats

  • Last update: 2021-04-09 at 09:47
  • Publication date: 2021-02-07 at 14:05
