Z Carriage for Eleksmaker laser A3/A5

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 666 views
  • 1 like
  • 18 downloads

3D model description

Designed to add a Z movement to my eleksmaker laser. (you need to upgrade to MANA (non SE) or CNC Shield to use it)

what you need:
2x - 110x8mm rods
1x - 170x8mm Stainless Steel Lead Screw Rod with Nut
2x - linear bearing (lm8uu)
2x - KP08 55x13x29mm Zinc Alloy Pillow Block Bearing
( all above in one kit: https://goo.gl/5oxCvE )
1x - Nema17 motor: https://goo.gl/gVgPXz
4x - tiny cable ties to lock lienar bearing to carriage
x - Some screw and nuts m3

See my first test in action: https://youtu.be/PCumGntcTvM

bye.


3D printing settings

-

3D printer file information

  • 3D design format: STL Folder details Close
    • Z_Carriage.stl
    • Z_Structure.stl
  • Publication date: 2021/02/25 at 14:20
