Wolfcraft Corner Clamp 90 degrees

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

Designer

3D model description

Wolfkraft clamps are very popular in Russia. They are sold in Leroy Merlin and perhaps they are worth the money they ask for them.

I often use these clamps, but I needed to glue the sides of the box and squeeze them strictly at an angle of 90 degrees.

For one set of corner nozzles, plastic consumption is about 1 euro, besides, they fit well and hold the load well.

These models of clamps in Russia have the following SKU numbers:

Wolfcraft 3020000 (150 mm)

Wolfcraft 3021000 (300 mm)

Wolfcraft 3023000 (500 mm)

Printing takes about 5 hours and 30 minutes.

You will get the best result with Cura profile Low Quality - 0.28 mm.

UPDATE 14.02.2022:

I added to the model small grooves for stationery rubber bands with a diameter of 60 mm, they are sold in many stores. Now parts of the model are held securely on the clamp, everything is simple and convenient. ( look at picture 2 )


3D printing settings

Printer: Artillery Sidewinder X1

Rafts: No

Supports: No

Resolution: 0.28 (Cura profile Low Quality - 0.28 mm)

Infill: 40%

Filament Brand: FDPlast

Filament Material: PLA

Do not rush to chamfer and process the part after printing! Let cool for 6 hours! Yes, yes, yes - the part will become smaller by 1, or even 2 tenths of a millimeter (depending on the plastic - but my FDPlast PLA decreases by 0.1 mm in only 3-6 hours.

3D printer file information

  • 3D design format: STL Folder details Close
    • Wolfcraft_Corner_Clamp_Bottom v9.stl
    • Wolfcraft_Corner_Clamp_Top v15.stl

    Learn more about the formats

  • Last update: 2022-02-14 at 08:27
  • Publication date: 2022-01-20 at 14:44
