DIY Fume Vent for the Wham Bam HotBox Line
:still():format(webp)/https://files.cults3d.com/uploaders/14343968/illustration-file/cc6be85d-dd47-4737-8d7f-3d35d99dccd8/resin_hotbox_exhaust-v15_03.png)
/https://preview3d-images.cults3d.com/4s4dctqeyc9je60sxobzs3o0vsk3)
/https://preview3d-images.cults3d.com/2nwbuyd33lltclyymleqjqtozcj4)
/https://preview3d-images.cults3d.com/v8hqy97wg550qdxe4eg6ogeahddg)
/https://preview3d-images.cults3d.com/vd7o7bpv7qh58i5ku8rvqe7oyutn)
?
Creation quality:
5.0/5
(1 votevotes)
Evaluation of members on the printability, utility, level of detail, etc.
Your rating:
0/5
- 1.5k views
- 3 likes
- 22 downloads
- 0 comments
- 1 make
Designer
3D model description
Use this exhaust fan on any FDM or Resin version of the Wham Bam HotBox (3d printer enclosure):
https://whambamsystems.com/hotbox
You will need:
Printable parts:
° Front_housing.stl
° Back_housing.stl
° Washer.stl
° LockNut.stl
Purchased Parts:
° 4 pcs M3 x 24 screws https://www.amazon.com/DYWISHKEY-Pieces-Stainless-Socket-Screws/dp/B07VT11DFM
° 2 pcs M3 x 6 screws or small wood screws to attach Front Housing to Back housing
° 1 pc 12V 60x60x25 fan https://www.amazon.com/gp/product/B07K2Y9XSH/
° 1pc variable 12V DC transformer: https://www.amazon.com/UTUO-Variable-Adjustable-transformer-brightness/dp/B08MZZPB53
° 1pc Vacuum hose and attachment set: https://www.amazon.com/gp/product/B01JROABYY
° Heat shrink wire connectors: https://www.amazon.com/dp/B07C3NBTJ9/
easy to assemble
https://youtu.be/5gyYx5ojLDU
see it in action!
https://youtube.com/shorts/Y7EfR03LD7w
3D printing settings
layer height 0.2
touching bed supports
orientation for housing part open side on bed,
3D printer file information
- Design number: 1096440
-
3D design format: STL Folder details Close
- Back_housing.stl
- Front_housing.stl
- LockNut.stl
- Washer.stl
- Last update: 2023-03-31 at 18:28
- Publication date: 2023-03-03 at 22:26
