ARTEMIS -> Magazine for Alligator 2 || 6.5" Arrows || Repeating crossbow

?
Creation quality: 5.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

Here you will get a addon that you can mount on your Alligator 2 to convert a standard crossbow with this magazin into a tactical crossbow. It will handle the standard (golden) 6.3"-6.5" Bolts.

New Features:
- 9 Bolts
- Foldable Magazine (Better maintanace)
- improved Lever, Stronger
- Dryfire safe
- Cool look

I took a lot of work, money, time into this project, so it will not be released for free.
You can download the stl files for a small amount, it will allow me to work on new projects.
Please take care that part of the price is charged by Cults for maintenance, banking costs and VAT.
If you want me to support more you can support me via PayPal. It do not have to be much, a price of a coffee would be awesome.
https://paypal.me/schnuffi84?country.x=DE&locale.x=de_DE

Supported arrows:
6.5" arrows -> See pictures
https://www.bogensportwelt.de/Alubolzen-BOLT-PL-65-Zoll-168er-10er-Pack

Supported crossbow:
https://www.bogensportwelt.de/X-BOW-Alligator-II-80-lbs-185-fps-Pistolenarmbrust-Farbe-Schwarz
https://www.kotte-zeller.de/pistolenarmbrust-alligator-ii-80-lbs-oliv-inkl-3-pfeile

Needed Material:
Around 250g-300g PETG
Srews (lens head)
10x M3 x 10mm (pikatini rails)
2x M3 x 10mm (Body Rear)
2x M3 x 12mm (Front mount)
4x M3 x 16mm (Trigger lock, Body front)
1x M3 * 14mm (lever)
1x M4 x 25mm Thumb screw
1x M4 x 25mm Lever Mount
1x M4 x 40mm Mount front
6x M3 Hex nut
2x M4 Hex nut (Self locking)
1 x M4 Hex nut (standard)

2x 8mm Steel ball
3x 8mm*0.8mm Spring / length = 14mm(trigger) / 14mm(leverlock steelball) / 18-20mm(lever)

(Small Printer 4x M3x10mm + 4xM3HexNut)

My eBay Account: (Tuning Trigger, Magazine etc.)
https://www.ebay.de/usr/schnuffischulz

Youtube:
Features:
https://youtu.be/I792_cqJmDk
Shooting:
https://youtu.be/UP30UPwyMg8
How to build:
https://youtu.be/-bsFAe5SLgg

Printing Time:
0.6mm Nozzle + 3Walls = 13hour

Disclaimer:
Make sure that this type of device is legal in your country.
I am not responsible for the consequences of building, possession and using this magazine. It can be dangerous in combination with a crossbow.
When not in use, always keep it under lock and key. Do not shoot living beings, use safty glasses and archery mat.

FAQ:
Question: "Could you load the bolts with broadhead into this magazine?"
Answer: Yes, but they have to be min 6.3" long. Otherwise they will cut the string.

Question: "I have only a small printer, can I also print this magazine?"
Answer: Yes, minmum bed size is 150*150mm. In this case you have to use the zip folder instead.
