Fine vacuum nozzles - narrow chisel tip for tight places

Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

One small and one very small nozzle for a vacuum cleaner, with an internal diameter of 35mm at the base.

These taper smoothly into a 5mm and 3mm throat, respectively, at the angled tip which should be just perfect for sucking dust out of the ways of your printer, or the fine one for inside your PC case and between keys if you don't have the luxury of an air compressor. If your vacuum can blow as well as suck, this ought to be pretty handy as a duster.

3D printing settings

No support needed. Skirt is adequate if you feel confident if your bed adhesion, else use a brim.
Model walls are 2mm at their thickest, so you might as well run 100% infill. I am using PETG for initial tests as the relatively straightforward shape doesnt cause much if any stringing issues and the strength and impact resistance is good. Gold standard would be polycarbonate, CPE, ASA or nylon.
Obviously print it pointy side up.

3D printer file information

  • 3D design format: STL Folder details Close
    • vacuum nozzle superfine.stl
    • vacuum nozzle.stl

    Learn more about the formats

  • Publication date: 2020-11-19 at 16:41





Hello! I am a tinkerer and engineering enthusiast from Christchurch, New Zealand.
I have an Ender 3 V2 and a Zonestar Z6FB.
I am glad to provide all my CAD work for free as an ameteur, but if you want to return the favour, please give feedback on any designs you print of mine!
