TwistLock Clamp

?
Creation's quality: 5.0/5 (5 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 12k views
  • 109 likes
  • 976 downloads

3D model description

This thread clamp is fully 3d printable with no supports, glue, or cleanup.

Check out the videos for assembly instructions and a clamping demo. You can also find my process for designing this thing here.

All parts of this clamp can be printed with standard settings, but if you want it stronger, print the knob.stl at 100% infill.

https://youtu.be/3ssV4AMFfRw
https://youtu.be/ekK4VG1ugyU

3D printer file information

  • 3D design format: STL Folder details Close
    • jawBottom.STL
    • jawTop.STL
    • knob.STL
    • pad.STL
    • pin.STL
    • retainer.STL
    • threadPin.STL
    • threads.STL
  • Last update: 2019/06/14 at 16:25
  • Publication date: 2019/06/05 at 10:00

License

CC BY NC SA

Tags

Creator

If you are interested in my design process and latest 3d printing experiments, check out my website and my Twitter
