SPUR GEAR SET #1 - MODULE 2

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 772 views
  • 2 downloads

3D model description

A set of 11 gears with the following characteristics:

  • Gear module 2mm
  • Inner hole 4mm
  • Number of teeth variable from 10 to 20
  • Thickness 10mm

To correctly couple them, the axis of the couple you consider, shall be placed at a distance given by:

axis_distance [mm] = number_of_teeth_grear_1 + number_of_teeth_gear_2

  • 3D file format: STL
  • Publication date: 2021/04/02 at 17:53
