Single part case LCD 12864, and LCD12864A/B, Full Graphic Smart Display

Creation quality: 5.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

Single part case 12864 LCD Full Graphic Smart Display

inspired from the great design of the "LCD MKS Mini 12864 Mount Enclosure Box Caja" by Campy :

BOM : 4x M3x12 screws

(Don't tight too much the screws to prevent warpage of the red board).

STL & STEP formats are available.

Edit 2018/12/01 : addition of a more compact version "v2"
Edit 2020/07/19 : addition of a new version only for LCD12864A/B from Makerbase ( )

3D printer file information

  • 3D design format: STEP and STL Folder details Close
    • LCD_12864A_12864B.step
    • LCD_12864A_12864B.stl
    • Single_part_case_12864_LCD_Full_Graphic_Smart_Display.step
    • Single_part_case_12864_LCD_Full_Graphic_Smart_Display.stl
    • v2_Single_part_case_12864_LCD_Full_Graphic_Smart_Display.step
    • v2_Single_part_case_12864_LCD_Full_Graphic_Smart_Display.stl

    Learn more about the formats

  • Last update: 2020-07-19 at 15:17
  • Publication date: 2019-12-20 at 15:36
    Published to Thingiverse on: 2018-11-13 at 01:23
