Sidewinder case - door for access of mainboard and displaycable

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 774 views
  • 6 downloads

3D model description

I made a 'door' in the case of the Sidewinder, instead of the 'grid' for the ventilation (on the right of the printer when looking at it). This makes the access to the mainboard and the cable that goes to the displayboard much easier: for flashing the firmware you don't have to open the case anymore. I attached it to the printer with 'velcro' after cutting the grid away.

When opened it provides a lot more ventilation then the original grid but when closed it gives extra protection (printer off!) against dust and fingers.
It also lets you see the status-LEDs on the mainboard during printing.

For Flashing firmware on the Sidewinder X1: open the little door when the printer is off, pull the cable to the display-board , connect the USB-cable to flash the firmware, when done, simply put the display-connection-cable back on, turn the printer on.
No need to remove the whole bottom of the printer anymore and retune because you moved the printer. Can all be done in place.

  • 3D file format: STL
  • Publication date: 2020/02/25 at 14:21

License

CC BY SA

Tags

Creator

I'm Elvin. I have a couple of 3D printers, mainly Anet. I make my own designs, mostly for usefull things; functional prints.
I also do testing of 3d printers and helping people to get on the path of 3d printing like putting a 3D printer to work.
