Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400

20230513_135429.jpg Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
20230513_135438.jpg Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
20230511_152109.jpg Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
20230513_135455.jpg Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
20230619_095225.jpg Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
20230619_095205.jpg Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
shark_adapter_to_35mm.stl Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
retainer_clip_v2.stl Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
35mm_insert_thread_in.stl Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
35mm_insert_thread_out.stl Shark Cordless Vacuum Cleaner Adapter for IZ200/IZ250/IZ300/IZ400
Advertising
Share
Add to
Make
?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
Licence CULTS - Private Use
Publication date 2023-05-13 at 03:28
Design number 1217700
3D design format
STL Folder details Close
  • 35mm_insert_thread_in.stl
  • 35mm_insert_thread_out.stl
  • retainer_clip_v2.stl
  • shark_adapter_to_35mm.stl

Learn more about the formats
Mart_Em

Mart_Em

3D printer file info

3D model description

Shark Cordless Vacuum Cleaner Adapter - created for IZ300UK model, but should fit all the latest Shark cordless vacuum cleaners (IZ200, IZ250, IZ300, IZ400).

There's 35mm round opening at the other end, to mount flexible hose or any kind of cleaning attachment, but I included a threaded insert with blank other end, it can be further redesigned to fit the attachment of your choice. That 35mm opening wasn't made for any particular attachment or tool. In my case, threaded insert that goes into the adapter requires only a little sanding on the outside, to make it "press fit" without using glue.

Required hardware: 28mm M3 screw and a spring of your choice to install the retainer clip. In my case, the clip fits perfect straight from the printer and hooks with the vacuum end easily, but without play.

Last photo shows adapter connected to the vacuum with Vax flexible hose connected to the other end (using another adapter, which then screws into Shark adapter).

Please rate and/or leave a comment. Thanks!

3D printing settings

Printed on Ender 3, with 0.6mm nozzle, 0.2mm layer height, wall thickness 1.2mm and 50% infill. Printed with supports, support type: tree, buildplate only.
Filament used: eSun PLA+ black, nozzle @ 215 C, bed @ 60 C.
