PTFE Tube Guide Filament Guide for Bambulab X1/X1C RS-CONCEPTS

Creation quality: 5.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.



3D model description

This "PTFE Tube Guide" prevents the PTFE tube from kinking above the extruder and also prevents the PTFE tube from grinding on the top of the glass pane.

The component serves as a replacement for the original component which fixes the PTFE tube to the extruder and is also screwed in place with the two screws. It also has some play like the original part and must not be screwed completely tight so that you can remove the PTFE tube with a downward pressure on the PTFE coupler.

The component is optimized for SLS printing. And is equipped with a "print in place hinge" to allow rotation/movement.

For FDM, the tollerances might need to be enlarged a bit.

STL is available for download and editing.

Those who wish to purchase the part in PA12 nylon as an SLS print can do so on our site:

3D printing settings

We optimized the part for SLS printing and printed it on our Fuse1.

For FDM, the part may need to be adapted or the tolerances increased.

3D printer file information

  • Design number: 1059843
  • 3D design format: STL Folder details Close
    • PTFE-Guide RS-CONCEPTS.stl

    Learn more about the formats

  • Publication date: 2023-02-12 at 11:04


CULTS - Private Use
