3D model description

Originally, the goal was to repair a broken Beach Parasol Foot.

This required the production of the two parts "Sunshade anchorage low and high".

In view of the encouraging results (after printing), decided to complete the design to eventually produce a complete support.

It is the latter, which is attached as *.stl files


  • This design is suitable for a Ø 25 mm rod. For use with a different rod, it is necessary to create a different clamping spacer or a specific adapter part.

  • The individual parts must be glued together at the time of assembly

  • After assembly, I applied an "XTC-3D" resin.

3D printing settings

Machine used: Anet A8

Object size: 412 x 86 x 79

Printing time: about 20 hours (not verified) - Layer height: 0.2 (small parts) - 0.3 (large parts)

Printing speed: 50 mm/s

Use of PLA wire 1.75 mm

Extruder temperature 200° C

Heated bed temperature 50° C

Application of a resin on the outside of the part to ensure waterproofing (for my part, I use "XTC-3D")

  • 3D model format: PDF, STEP, and STL
