3D model description

We upgraded to the G8 Lens (see more here: http://diy3dtech.com/G8-Laser-Lens ) for our Ortur Diode Laser (see more here: http://diy3dtech.com/ORTUR_Laser_Master ) which is amazing! However the new G8 lens barrel would not fit into the existing lens mount so we designed a new one in Fusion 360. Please note there are two versions as an FDM print is not capable of printing the find threads so there is an SLA version and an FDM version as the SLA version has the modeled threads and the FDM is stepped with press [in] and twist sort of self tapping idea. Note: we have also included the Fusion 360 files too!
