Nail Puzzle Box

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 1.1k views
  • 2 likes
  • 37 downloads

3D model description

This is a puzzle box that I was inspired to make after I saw a few people solve a wooden version of this on Youtube. The goal is to open the box but it is locked and has nothing on the outside. It is good showpiece, piggy bank, or storage container for secret things. It would also be pretty cool if used for geocashing. Scroll down for the solution to open this box.

The mechanics are pretty simple and it is easy to assemble. 7 nails and a little glue is needed to complete the project. The nails need to be less than 0.4cm in diameter and at least 6.5cm long. The glue is just for one piece on the inside.

Feel free to leave a comment or post a make. Also, if you liked this, check out my other puzzles and designs.

To solve this puzzle, slide the nails back and forth to loosen them up. Then, using some force, quickly spin the box in a circle. The centripetal force will push all the nails in opposite directions, unlocking it. Then, gently lift up the lid which should freely slide out.

Update: If the nails don't fully slide all the way when spun, spin the box the other way.

3D printing settings

Printer Brand:

Prusa

Printer:

i3 MK2S

Rafts:

Doesn't Matter

Supports:

No

Resolution:

0.2mm

Infill:

10%

  • 3D file format: STL
  • Publication date: 2018/06/27 at 16:25

Tags

Creator

Designs 22
Downloads 2.8k
Followers 22

My name is Arden Markin and I have been extremely passionate about 3D-printing and modeling ever since I got my 3d printer. I am still in high school and any extra time I have is spent in modeling, cardistry, or chess. I am also a huge Nintendo fan.

License

CC BY NC
