My Customized Parametric pulley - gt2 20

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

Customized version of http://www.thingiverse.com/thing:16627

Created with Customizer! http://www.thingiverse.com/apps/customizer/run?thing_id=16627


3D printing settings

Using the following options:

idler = 1
nut_shaft_distance = 2
retainer_ht = 1.5
pulley_b_dia = 20
additional_tooth_width = 0.2
nut_angle = 90
additional_tooth_depth = 0
retainer = 1
teeth = 20
pulley_b_ht = 8
idler_ht = 1.5
motor_shaft = 8.1
m3_nut_hex = 1
no_of_nuts = 1
profile = 2
pulley_t_ht = 12
m3_nut_depth = 2.7
m3_nut_flats = 5.7
m3_dia = 3.2

3D printer file information

  • 3D design format: STL Folder details Close
    • pulley_t-mxl-xl-htd-gt2_n-tooth_20161007-11618-34580k-0.stl

    Learn more about the formats

  • 3D model size: X 20 × Y 20 × Z 21.5 mm
  • Publication date: 2020-04-23 at 12:52
    ?
    Published to Thingiverse on: 2016-10-07 at 15:50

License

CC BY SA
