McGrid - The Snap-on grid for Aputure AL-MC (60° & 90°)

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

This is McGrid, our own snap-on grid for the Aputure AL-MC, in two different light-spread variants.
You get a 60° grid and a 90° grid for total control over light spill, as well as a protective case.

The different STL files:

  • AL-MC_Grid_60degree – this is the snap-on grid featuring a 60-degree angle
  • AL-MC_Grid_90degree – this is the snap-on grid featuring a 90-degree angle
  • AL-MC_Case_Grids+MCs – this is the protective case that can fit two MCs and each grid
  • AL-MC_Case_onlyGrids – this is the protective case that can fit both grids but no MC

Please follow the placement instructions on the pictures, otherwise you might not be able to fit the items into their protective cases.

If you like our work, please consider following us on Instagram, Facebook, TikTok, LinkedIn and please mention us in your posts :)

Of course, you are allowed to use your prints for commercial purposes like video shoots, etc, but you are not allowed to sell our products; not in digital form nor in printed form.

If you have further questions, please don't hesitate to contact us at
www.sincerepromotions.com/contact


3D printing settings

All products work with PLA but the grids will be a little more sturdy if you print them with ABS.

Quality: 0.15mm
Infill: doesn't really matter. We used 15%
Important: activate "detect thin walls" for printing the grids. This will reduce the printing time by 50%
Size: 100%
Supports: None

We printed on a Prusa i3 MK3S+.

Be careful not to overbend the latch or it will break. However, the grid still has a tight fit without the latch and in most situations, the grid won't fall off the MC. Still, the latch offers more security, so that the grid won't come off.

3D printer file information

  • 3D design format: STL Folder details Close
    • AL-MC_Case_Grids+MCs.stl
    • AL-MC_Case_onlyGrids.stl
    • AL-MC_Grid_60degree.stl
    • AL-MC_Grid_90degree.stl

    Learn more about the formats

  • Publication date: 2022-04-12 at 19:48
