m6.5 2p nut

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 182 views
  • 8 downloads

3D model description

Customized version of http://www.thingiverse.com/thing:193647

use with this bolt - http://www.thingiverse.com/thing:936436


3D printing settings

Using the following options:

thickness = 2
thread_length = 7.5
resolution = 0.5
nut_type = normal
nut_step_shape_degrees = 45
facets = 6
nut_resolution = 1.0
non_thread_diameter = 0
countersink = 2
thread_outer_diameter = 5.5
head_height = 5
nut_height = 5
step_shape_degrees = 45
non_thread_length = 12.5
texture = exclude
type = nut
outer_diameter = 14
slot_depth = 2
nut_diameter = 10
drive_type = socket
nut_thread_outer_diameter = 6.5
wing_ratio = 1
drive_diameter = 5
head_type = hex
nut_thread_step = 2
thread_step = 2
head_diameter = 10
slot_width = 1
inner_diameter = 8

3D printer file information

  • 3D design format: STL Folder details Close
    • nut_job_20150722-25928-1227hgs-0.stl

    Learn more about the formats

  • 3D model size: X 11.5 × Y 10 × Z 5 mm
  • Publication date: 2021/02/19 at 09:49

License

CC BY SA
