There are knurling bolts and a nut that modeling on Autodesk Fusion 360.

I've prepared a bolt of various lengths.
So, print a bolt you want.

Bolts are M16, pitch 2.0, length 20, 30, 40, 50, 60mm, and Head OD 30mm, height 20mm.
A nut is M16, pitch 2.0, height 20mm.

See my YouTube about how to making a knurling on Fusion 360 https://youtu.be/wNVtLVF99cw

"Knurling bolt and nut" are compatible with "Yet another knurling bolt and nut" (https://cults3d.com/en/3d-model/tool/yet-another-knurling-bolt-and-nut).
