NOW INCLUDED THE BACK PLATE FOR THE CR-10S, NOT MY FILE BUT IS PART OF THE rev 2.x VERSION or V2 i have up, it will screw right into as i didnt change anything to those parts just added in some extra

okay so i remixed the reversible hinge, LCD screen mount for ALL in one setups, print ready latch, and added some of m,y own touch in there.
building my enclosure i wanted to mount my control box under the table like robert has his though my table is lower to the ground and i have a giant dog that likes to mess about some, so i couldnt have it stationary bolted to the side of my table... besides id probably roll into it with my chair and also im a fan of hiding things out of sight until needed for use.

so i took the mount first and made it so it was flat laying and then added some further walls and cut off the back angled section and removed the angled mounting tab it had, i then replaced the mounting tab with the print ready reversible hinges and added some mounting holes so i can mount it to hang on the front of my table.

i then used the short hook and attached that to the side of the box at the bottom so it will be the holding piece for the hanging clip.
i took the latch itself and cut it in half removing the mounting area but leaving the bar and flip tab. then duplicated that and removed the bar and the a section of the top and added some wedge braces to make it look uniform and add some strength. then i added holes to mount the hanging hook and also added extensions to the bar incase i dont want it to be fully pinned up or the length didnt work out as planned. either way for my needs this will work and hopefully some others will get some use from this as well!
