Helping hands clamp adapters for dial indicator holder

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 👁 366 views
  • 1 download

3D model description

These files are for adapters to turn standard dial indicator holders with 8mm mounting holes into the world's best helping hands clamps for holding small items. I like this style of helping hands better than any other that I've tried.

There are 3 adapters: 1 accepts an alligator clip, another accepts a small spring clamp, and the last accepts a brass model-maker's clamp with a 3mm bar. The alligator clip and spring clamp are glued in place, and the model-maker's clamp is held in by an M4 screw.


3D printing settings

-

3D printer file information

  • 3D design format: STL Folder details Close
    • Alligator_clamp_adapter.stl
    • Model_maker_clamp_adapter.stl
    • Spring_clamp_adapter.stl

    Learn more about the formats

  • Publication date: 2021/10/12 at 01:11

License

CC BY
