Geeetech A10 - Marlin 2+Slic3r profile+Maker Coin Akos W.

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 385 views
  • 3 downloads

3D model description

Update 10.10.2018: A newer A10 was spotted in the wild, with filament sensor and Power out feature, which has the GT2560 v3.0 board. This firmware should work but was not Tested on the New Firmware.

Update 31.08.2018: some of you might be getting a "Path not found error". After unpacking move the main folder somewhere to shorten the folder path. Windows only accepts max. 260 characters as folders.
!!!Use ONLY Arduino IDE 1.8.5 for compiling and uploading!!!
Also uploaded a .hex file of the compiled firmware if someone would like to upload it directly to their printer.

PLEASE READ

Just a couple of introductory and instructions to this Firmware/Profile package:

!!!Firmware retract is enabled in Firmware and Slic3rPE profile as well!!!
default retract setting: 2mm @ 35mm/s

Start Script behavior/features in this profile for the A10:

  • Preheat Nozzle and Bed simultaneously to temperature defined in settings ;---------------------------
  • Home all 3 axis
  • Auto bed leveling(it will be skipped if you don’t have a sensor) ;---------------------------
  • Parking to right-back of the bed
  • lowering the nozzle to touch the bed to stop oozing while preheating ;---------------------------
  • continuing heating ;---------------------------
  • draws a priming-line to the front ;--------------------------- sets Linear Advance K value to 0.75, to disable LinearAdvance_set this to 0 ;---------------------------
  • START printing

Marlin 2.0.x bugfix version with enabled advanced features:

-Babystepping - during printing: LCDMenu->Tune->Babystepping or DoubleClick Wheel
-Advanced Pause Feature
-LCD_Info Menu & Printcounter (LCDMenu->About Printer->Printer Stats)
-EEPROM enabled (M500 and M502)
-Firmware retract (LCDMenu->Control->Retract->...) is already

!!!Make sure after Firmware Upgrade you run M502 and M500 gcodes to load and save default settings!!!

HAPPY PRINTING!

Ákos W.

3D printing settings

-

  • 3D file format: STL and ZIP
  • Publication date: 2021/03/11 at 01:34

Tags

Creator

License

CC BY SA
