FABtotum PCB Engraving fixture

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 684 views
  • 3 likes
  • 15 downloads

3D model description

A PCB fixture for laser engraving / PCB milling on the FABtotum Personal fabricator/ CORE /CORE Pro.
To use with the Milling head or Laser head.

It sticks into the milling side of the print bed pro.
For laser engraving no screws are necessary.
It can be secured for milling as well (see optional screws).

Two sizes available for Euro Cart standard (100x160, 100x60).

Optional:
4X M4 screws + nuts (to secure the fixture on the print bed)
4X M3 screws + nuts (to secure the PCB copper clad for milling)

3D printing settings

Printer:
FABtotum personal fabricator CORE

Rafts:
Doesn't Matter

Supports:
Yes

Resolution:
0.1mm

Infill:
25%

Notes:
Nothing extraordinary about print settings.
