Ender 3 Briss fang Gen2, Red lizard, Spider, Revo, dragonfly, etc.
- 47.1k views
- 187 likes
- 702 downloads
- 95 comments
- 14 makes
3D model description
An other original Briss Moto design
My designs are protected by copyrights laws. It is not authorized to distribute or sell any of my designs without prior written authorization from myself. Even if you modified my original design. Thank you
Edit: does not fit ender 3 neo, ender 3 max, ender 3 s1 or any other variations that does not use the same hot end and housing bolt pattern as the original ender 3 or ender 3 v2.
I am now an amazon affiliate. I will get a small profit from these which will allow me to put more time in these projects.
Noctua A4x20 12v: https://amzn.to/3JNWYuI
Noctua a4x10 12v (for motherboard) : https://amzn.to/42Ux69l
Winsin 4020 fan 24v : https://amzn.to/42Pdvap
Arctic High flow 4028 fan 12v (noisy though): https://amzn.to/3M2C6mj
Buck converter: https://amzn.to/40jkKWt or https://amzn.to/3G52gRA
5mm straw hat LEDs : https://amzn.to/3KloNMy
Ender 3 micro swiss direct drive : https://amzn.to/3nBWWOU
CR touch : https://amzn.to/40nFgVU
Creality spider v2 hot end : https://amzn.to/3M2PQ09
Creality spider v3 hot end : https://amzn.to/3G2uqN5
bimetal heatbreak : https://amzn.to/42Qv2Pu
Dragonfly BMS : https://amzn.to/3ZrKdf2
M3 bolt kit : https://amzn.to/40NzDQy
2023-04-09: Adding Fang for ender 3 compatible with Revo micro using this mount (https://www.thingiverse.com/thing:5200613)
2023-01-03: Adding printed direct drive bracket for the creality aluminum dual gear extruder.
2022-06-20: Adding fangs compatible with the Micro Swiss direct drive (the standard one, not the NG) and NOT for linear rail version either (that will be coming up later).
Also adding a printed direct drive bracket for stock motor and extruder.
New fang based on my original and popular design, made to use two 40mm axial fans but made to fit around bigger hot ends and supply twice the airflow for high flow nozzles and high deposition rates. In the following weeks I will design adaptors to use Orbiter extruder and make it fit some more printers. Right now only fits ender 3, ender 3 pro and ender 3v2.
-Improved fang support on the right side
-Double the airflow
-Repositioned hot end fan for increased nozzle visibility
-Modular wire management
-Modular accessory mounts on each side (BL touch, CR touch, EZABL (coming soon), etc.) BL touch offset: x-54 and Y-27
-Built-in LED mounts for 5mm straw hat LEDs
-Still prints with no supports at all, some supports are built-in the model and you snap them off at the end
Comes in different length for the different hot ends. *@ Length measured from the center of the hot end mounting holes to the tip of the nozzle @* PLEASE MEASURE YOUR HOT END, there are copies, variations and new products released regularly.
51mm : Creality Spyder (Measure your hot end carefully, there are at least 3 versions out there with different size)
49mm: Mellow NF crazy
47mm: Creality Mk8 (stock ender 3 hot end)
Creality Spider v2
Red lizard V2
Red lizard V5 pro
Phaetus Dragonfly 7 fins (warning, there is a shorter 6 fins version out there too)
45mm: Phaetus dragonfly 6 fins
Red lizard Q1
I tested a high flow 4028 fan for parts cooling
sanyo-denki 109P0424R3013, Flows more than 5015 blower. Only drawback is that when slicer is set at 1%, it already spins at about 50% of maximum speed. And it's pretty noisy of course at 14000rpm.
Please let me know if you have any issues, this is a new design and could need some tweaks.
3D printing settings
0.4 or 0.6 nozzle
0.2 mm layer height
Steep 60deg overhangs, harder to print with some materials. proper printer set-up and calibration recommended.
45deg duct is also 60 deg overhang. i recommend using thinner layers, slower print speeds and print with a material that is easy to print with.
3D printer file information
- Design number: 727099
3D design format: STEP and STL Folder details Close
- 40mm duct 45 deg.STL
- ADXL345 mount.STL
- Briss fang V5 Ender 3 all 45mm.STL
- Briss fang V5 Ender 3 all 47mm.STL
- Briss fang V5 Ender 3 all 49mm.STL
- Briss fang V5 Ender 3 all 51mm.STL
- Briss fang V5 ender3 MS DD 45mm.STL
- Briss fang V5 ender3 MS DD 47mm.STL
- Briss fang V5 ender3 MS DD 49mm.STL
- Briss fang V5 ender3 MS DD 51mm.STL
- Briss fang v5 REVO micro 45mm.STL
- Briss fang v5 flow control.STL
- Direct drive Dragonfly adaptor.STL
- Dragonfly adaptor.STL
- ENDER6 Briss fang v5 47mm.STL
- Ender 3 printed direct drive for aluminum dual gear extruder.STL
- ender3 v2 Orbiter 2.0 adaptor v2.STL
- ender3 v2 sherpa mini adaptor v2.STL
- printed direct drive for OEM extruder.STL
- short extruder knob.STL
- side adaptor blank.STEP
- side adaptor blank.STL
- v5 cr touch mount 45mm.STL
- v5 cr touch mount 47mm.STL
- v5 cr touch mount 49mm.STL
- v5 cr touch mount 51mm.STL
- wire stress releif adaptor blank.STEP
- wire stress releif adaptor blank.STL
- wire stress releif adaptor direct drive.STL
- wire stress relief adaptor.STL
- Last update: 2023-04-26 at 06:48
- Publication date: 2022-05-17 at 04:45
