Dowel Jig

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 2.7k views
  • 17 likes
  • 152 downloads

3D model description

Simple dowel jig i designed. It's for 16mm wood and a 8mm dowel. I placed 8 mm Bearing Bushing in the printed hole to help protect the plastic from the drill. !Don't forget to CHECK OUT my other designs and FOLLOW my daily uploads, Enjoy ;)

You will need:
* Bearing bushing 8x11x22mm aliexpress
* Bolt and nut m3
* Drill for wood 8 mm aliexpress

3D printing settings

Printer:ZAV
Rafts:No
Supports:No
Resolution:0.2
Infill:20%

  • 3D file format: STL
  • Publication date: 2018/08/31 at 14:52

Tags

Creator

Designs 10
Downloads 1.2k
Followers 11

License

CC BY
