Customizable Leveling Test

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

A bed leveling test where you can customize parameters like:

  • Printer bed size (Bed X / Y) - 100 to 500mm
  • How many points for mesh you are using (X / Y Points) - 2 to 10
  • The nozzle size (to ensure it will print full lines) - 0.1-1.0mm (showed as 1 to 10)
  • Wall line count (perimeters) - 1 to 4
  • If you want filled shapes or just an outline
  • Square of circle shapes
  • Just shapes without lines between

Model is 0.2mm high

ver1.01


The model size (footprint) is 8,5% smaller than the set bed size
Default values are for Ender 3 (235x235), 5 points Bed Leveling with double lines of 0.4mm and without filled shapes (prints fast, doesn't use much filament)

I recommend to leave empty shapes and double lines


In files there is an stl for 305x305 bed with 5points leveling for JG Maker A1 (or other printers with such bed)
You can generate an stl to any other bed sizes and options on your own

To customize a model and make an stl file

  • open the file in OpenSCAD
  • set the parameters
  • push F6 to render
  • and then export to STL

A NOTE:
I don't know where exacly auto or manual bed leveling check points on the bed but it should be rather close where it is generated from my file (at least with 5 points and less)

It was tested only in the slicer (with few different parameters)

It's my first OpenSCAD file and first customizable model but everything should work fine


To level the bed:

  • clean the bed
  • level corners
  • use bed leveling
  • print generated file After printing edit your mesh (X0 Y0 is you first point where leveling started) and do the changes to hight based on how the print is looking in this part. Then go for another point (X1 Y0 etc.)
