ENDER 3 S1, S1 PRO, 2020 ALU PROFIL, SPOOL HOLDER AND DEPORTED SPOOL

Bobbin holder for Creality Ender 3 S1/S1 pro 3D printer and probably also compatible with other models that have a 2020 mm aluminum profile (20x20mm).

Allows the spool to be placed in the opposite direction, giving a more evenly distributed weight and eliminating the plastic protrusion below the aluminum profile that sometimes interferes with the printhead cable on large prints.

You can use it on the left or right or even one on each side to place two spools of filament.

/!\ The roll axis is the basic one, to be recovered from your original support. You can find similar files to print if you need an axle. Space for the coil is 87 mm maximum.

Information for installation

The *Low Support" can be installed on the aluminum profile without screws, but you can also add a screw and a T-Nut on the holes at the back of the part.

Filament spool placed on support:

• The "Clip holds small spool" clip holds smaller filament spools on the spindle.

Remote filament spool:

• The "Filament ring spool deported" and "Filament guide spool deported" parts allow you to place the spool elsewhere on your desk for example with a filament dryer like the Sunlu Filament Dryer S2. You can place the parts on the left or right of your printer - they are symmetrical.

• To mount the "Filament ring spool deported" you'll need an M5x12 screw and a T-Nut for fixing in the aluminum profile. You should have received two with your printer.

Thanks to Brian Diffenbaugh for modeling the filament spool.

0.4 mm nozzle

Coating thickness 0.20 (base support) and 0.16 mm (other parts)

20% filling

Supports 40° angle
