Bambu AMS Stand for Placing raised 2nd Unit behind

?
Creation quality: 4.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.

Designer

3D model description

Bambu AMS Stand for Placing raised 2nd Unit behind.

Slots into the underside of the AMS, to raise the the unit to be seen / accessed behind a additional unit, whilst Clearing the front units Bowden and Controller Lead

The legs slot tightly into the AMS unit from the underside to raise the unit above the cables of any unit in front

The center uprights to the legs lock tightly into a void on the underside , and provide a tight fit, so if you deceide to glue before doing so ensure you have nothing preventing the fit being flush with a test fit. (Mine isn't glued)

Now also included Stand for Mk3 AMS with adjusted Hole widths and positions - In theory this should work with Both AMS's , however untested, If you do have both AMS types and are able to test, and it fits, please let me know so can update description, Thanks


3D printing settings

This is a multi part piece so can be printed on the Bambu XC1

You will need to print 4 parts in total , 2 of each for each side.

I printed at .2 Layer , units prints on their sides with the curved leg parts upright, and after first layer they printed fine on ludicrous, they are slotted to assemble, but a bit of superglue can be added on the joint for added strength if you wish (I don't have mine glued)

I printed with 20% gyroid infill in PLA, as they are printed on the sides, this should be plenty strong enough due to direction of print designed to add strength.

Use Auto Dynamic Supports if printing on XC1`, this places a small support in the opening to the insert which easily snapped out to clear

They are printed in 2 parts to allow them to print on a XC1, I am happy to provide a one piece design if required.

3D printer file information

  • 3D design format: 3MF and STL Folder details Close
    • Ams Stand (Extended Holes PT1 for Mk3).stl
    • Ams Stand (Extended Holes PT2 for Mk3).stl
    • Ams Stand PT1.stl
    • Ams Stand pt2.stl
    • Bambu Ams Stand.3mf

    Learn more about the formats

  • Last update: 2022-12-15 at 17:06
  • Publication date: 2022-11-12 at 21:50
